Installation Design for Large-Campus Restroom Systems
Airports, hospitals, universities, stadiums, and corporate parks.
Coordinated hydraulics • electrical & data • mounting/structural — built for safety, throughput, and maintainability.
Hydraulics & recirc loops
PoE gateways & telemetry
ADA & seismic
BIM-ready
Installation Design — Large-Campus Restroom Systems
Large campuses demand coordinated design across hydraulics , electrical/data , and mounting/structural systems. Zoning by wing/floor, pressure regulation, and hot-water recirculation keep flows stable during peak loads. Distributed power and PoE raceways enable smart telemetry and BMS integration. Reinforced backers, ADA heights, drip trays, and freeze/seismic protection ensure durability and safety.
Executive summary
Hydraulics & Supply
Zoning by floor/wing, PRVs, shock arrestors, and recirculation loops keep delivery balanced across sprawling campuses.
Electrical & Data
Dedicated circuits, PoE/Cat6 raceways, and gateways per 25–50 fixtures power smart telemetry and BMS (BACnet/IP, Modbus TCP, MQTT) integrations.
Mounting & Structural
Reinforced backers, ADA heights, drip trays, seismic restraints, and freeze protection extend service life and reduce emergency calls.
Installation Focus Areas
Hydraulics
Zoning, PRVs, shock arrestors, return loops, and central mixing with ASSE 1070 point-of-use tempering. Specify 0.35–0.5 gpm lavs; pair bowls/valves correctly.
Electrical & Data
Low-voltage/PoE raceways, distributed gateways, and reliable power for smart fixtures. Use BLE/IR for commissioning; enforce VLAN segmentation and TLS.
Structural
Reinforced mounting, ADA compliance (≤34" AFF lavs), drip trays, seismic bracing, and freeze protection for exterior walls and cold climates.
Engineering & Facilities Playbook
Hardware hardening — Faucets & dispensers
316 SS or DZR brass, PVD finishes, ASSE 1070/1017 mixing, ToF/IR sensors, IP65+ electronics, hot-swappable batteries or PoE, front-serviceable modules.
Soap system — Heavy traffic
Peristaltic/diaphragm pumps, 5–10 L central reservoir feeding 6–8 heads, leak/level sensors, auto-purge and filtration to prevent clogs.
Controls, telemetry & BMS
BLE/IR commissioning, gateways (BACnet/IP, Modbus TCP) or MQTT, usage/fault telemetry, webhook/CSV exports to CMMS.
Hygiene, safety & compliance
NSF/ANSI 61/372, ADA, IPC/UPC; programmable Legionella flush & thermal shock; laminar outlets for healthcare/food zones.
Environmental & sustainability
EPD/HPD availability, low-flow credits, occupancy-aware conservation, anomaly detection for leaks & stuck valves.
Maintenance model & SLAs
3-month & 12-month cadences, hot-spares 5–10%, MTBF targets; KPIs: uptime ≥99.7%, repair <20 min, stockouts <1%.
Project Gallery
Airports
Zone-by-wing hydraulics with return loops and BMS telemetry.
Hospitals
Central mixing, POU checks, laminar outlets, seismic restraints.
Stadiums & Universities
Reinforced backers, drip trays, freeze protection for exterior walls.
Video Showcase
VIDEO
Installation: Touchless Faucets
How Fontana touchless faucets are installed and commissioned in real-world settings.
VIDEO
Product Focus: Integrated Faucet + Hand Dryer
Performance, finishes, and hygiene benefits for high-traffic environments.
Resources for Contractors & Architects
Touchless Sensor Faucets (Catalog)
Browse commercial touchless faucets with finishes and flow options.
Automatic Soap Dispensers (Catalog)
Deck & wall-mount; multifeed-ready options for high-traffic zones.
Architects & Designers Hub
Spec guidance, finishes, and sensor tech overview for design teams.
Request Spec Kit & BIM
Get installation guides, hydraulic zoning diagrams, PoE raceway layouts, seismic/freeze specs, and ADA details.
