Fontana Napoli Deck Mount Chrome Finish Commercial Automatic Sensor Faucet

Milan Commercial Automatic Hands-Free Faucet offers a streamlined touchless solution for commercial restroom infrastructures where durability, sanitation, and resource efficiency are essential project considerations. The integrated sensor system enables consistent activation accuracy while minimizing user contact with restroom fixtures. Conventional automatic faucets often suffer from electronic instability, flow inconsistencies, delayed shutoff cycles, and premature component wear that increase facility operating costs. This commercial-grade model is designed to withstand continuous usage while maintaining dependable functionality and reduced maintenance requirements. Recommended for government facilities, transportation hubs, healthcare environments, hospitality properties, and institutional developments requiring specification-level performance.

Napoli Sensor Activated Faucet Special Features:

• Durable Vandal-Resistant Brass Body; Ideal for commercial high use applications
• Intelligent: with its micro-computer controlling its action, the faucet will self-adjust its best detection zone as per the color and shape of the lavatory
• Flashing light indicator; a diagnostic indicator for power up, low battery, and solenoid function.
• The meanings of the codes are described in the installation instructions.
• Convenient to maintain; with a built-in strainer to prevent sundries from entering the solenoid valve and the strainer is easy to clean
• The faucet can be mounted to any sink surface.
• The battery's life is 8,000 cycles per month and with enough water pressure is approx 5 years service life of the batteries.
• Adjustable sensing range; while the factory range is set about 4" to 5" from the sensor, it can be adjusted.

Napoli Faucet Specifications

• Diameter of inlet pipe: DN15
• Diameter of outlet pipe: DN15
• Water Pressure: 0.05Mpa - 0.7Mpa
• Power and Voltage: DC.6V / AC.110-220V - 50/60Hz
• Power Consumption: 0.5MW / <2W
• Finish: Chrome
• Model Number: FS-501
• Material: Solid Brass
• Installation Type: Deck Mount
• Deck Plate: Yes
• Valve Type: Solenoid valve
• Hot and Cold Water: Optional
• Detection Zone: Factory set 25cm/10" (based on standard inductive board)
• Ambient Temperature: 1 - 45 °C / 33.8 -113 °F
• Degree of protection by enclosure: 1P56
• Battery: 4 x 'AA' size cells
• Operational water pressure range: 0.05 - 0.6MPa
• Water supply pipe size: DN15
• Overall Height: 4.5"
• Deck Plate Height: 6"
• Deck Plate Width: 2.2"
• ADA Compliant
