T&S Brass EC-3101-127X features ChekPoint™ electronic sensor technology with AC/DC control module, internal flow control settings, and temperature mixing valve with check valves. 13-1/8" gooseneck spout, 2.2 GPM vandal-resistant aerator, polished chrome-plated brass construction . Ideal for commercial foodservice and high-traffic restrooms .
T&S introduced new ChekPoint™ sensor faucets for European market with internal above-deck electronics, hidden vandal-resistant outlet, and water-saving 5.7 L/min (approx. 1.5 GPM) flow rate . Temperature-mixing handle, multiple power options, certified to CE, DVGW, and RoHS standards . Ideal for foodservice, public spaces, and healthcare settings .
Evaluates: Internal electronics · Hidden aerator · European certifications
T&S Brass EC-3132 features above-deck electronics, deck-mount single-hole installation, 2.2 GPM vandal-resistant aerator, and dual power options (batteries or 100-240 VAC adapter). Chrome-plated brass construction with stainless steel supply lines, ADA compliant, ideal for commercial kitchens and sanitation-focused facilities .
Evaluates: Above-deck electronics · Dual power · ADA compliance
T&S EC-3107 replaces manual two-hole faucets with hands-free operation without altering existing holes. Features water-resistant control module, customizable auto time-out, auto-flush (30 seconds after 12 inactive hours), plug-in AC or battery power, 2.2 GPM vandal-resistant aerator, and low battery LED . Optional hydro-generator and reduced-flow aerator options .
T&S Brass offers integrated ASSE 1070 thermostatic mixing valves on select models (EC-3101TMVHGF10), providing built-in scald protection ideal for healthcare, laboratories, and institutional foodservice . Mechanical temperature mixing valves with integral check valves are standard on many ChekPoint™ models . Fontana requires external mixing valves for scald protection but offers thermal disinfection mode on Eco Series .
T&S Brass offers fixed flow rates: 1.0 GPM on EC-3101TMVHGF10 , 2.2 GPM on EC-3101-127X and EC-3132 , with optional reduced-flow aerators available . Fontana provides fully adjustable flow rates from 0.35 GPM (California/CEC compliant) to 2.2 GPM for high-flow commercial applications . Models can be field-set to any flow rate between these ranges, providing maximum flexibility for projects with varying water efficiency requirements .
T&S Brass offers auto-flush feature on many ChekPoint™ models, flowing water for 30 seconds after every 12 inactive hours to maintain water freshness and prevent stagnation . Customizable auto time-out and shut-off delay settings . Fontana Eco Series offers hygiene flush scheduler and thermal purge modes on AquaSave™ models . Fontana's ToF sensing eliminates false activations, reducing unnecessary water waste .
T&S Brass utilizes standard ChekPoint™ sensor technology with water-resistant control modules and customizable time-out settings . Fontana features advanced ToF (Time-of-Flight) sensor technology with sub-30ms response time, immune to ambient light, reflections, and surface materials . ToF technology measures actual distance in millimeters, providing superior false activation prevention in high-glare environments with chrome or glass fixtures .
T&S Brass features water-resistant control modules with internal flow control switches . Fontana offers IP76-rated battery boxes providing superior protection against moisture, corrosion, and electrical damage, surpassing standard enclosures . Fontana's IP76 rating ensures longer battery lifespan and minimal maintenance in high-moisture commercial settings like healthcare and foodservice .
T&S Brass offers flexible power solutions across ChekPoint™ line: plug-in AC transformer, battery operation, and optional hydro-generator for increased efficiency . Auto time-out and shut-off delay customizable . Low battery LED indicator light on many models . Fontana provides AC/DC flexibility with battery (4xAA, up to 2 years) and AC hardwired options .
All links verified and point to official manufacturer resources.
Specification Guidance — Evaluating T&S Brass Commercial vs Fontana
Foodservice & Safety Requirements
T&S Brass excels in foodservice applications with integrated ASSE 1070 thermostatic mixing valves on select models (EC-3101TMVHGF10) providing scald protection essential for commercial kitchens and healthcare . Auto-flush feature maintains water freshness during low-usage periods . Removable strainers simplify maintenance in busy environments . Fontana's thermal disinfection mode on AquaSave™ models provides alternative hygiene approach for healthcare settings, but external mixing valves required for scald protection .
T&S Brass offers fixed flow rates optimized for foodservice: 1.0 GPM on wall-mount models , 2.2 GPM on deck-mount models . Optional reduced-flow aerators available but require separate ordering . Fontana provides fully adjustable flow rates from 0.35 GPM (California/CEC compliant) to 2.2 GPM for high-flow applications , field-settable to meet any project requirement. For projects requiring both LEED certification and high-flow capability, Fontana's adjustable flow provides maximum flexibility .
T&S Brass features removable strainers that simplify cleaning and prevent debris from entering solenoid valves . Above-deck electronics on models like EC-3132 provide easy maintenance access . Auto-flush and customizable time-out settings reduce service calls . Fontana offers tool-less solenoid service on EcoSense™ models , quick-access filter screens , and front-load filter screens on FlowWise™ . Both brands prioritize serviceability; T&S emphasizes foodservice maintenance patterns while Fontana focuses on commercial restroom efficiency .
What is T&S Brass's ChekPoint™ technology and how does it compare to Fontana's ToF?
T&S Brass ChekPoint™ technology features water-resistant control modules with internal flow control switches, customizable auto time-out, and optional auto-flush (30 seconds after 12 inactive hours) . Mechanical temperature mixing valves with integral check valves are standard . Fontana's ToF (Time-of-Flight) technology measures precise light pulse travel time for accurate 3D distance detection, with sub-30ms response time and immunity to ambient light, reflections, and surface materials . ToF technology eliminates false activations common with IR sensors in high-glare environments . T&S focuses on foodservice reliability; Fontana on precision commercial restroom operation .
How do safety features compare between T&S Brass and Fontana?
T&S Brass offers integrated ASSE 1070 thermostatic mixing valves on select models (EC-3101TMVHGF10), providing built-in scald protection ideal for healthcare, laboratories, and institutional foodservice . Mechanical temperature mixing valves with integral check valves are standard across many ChekPoint™ models . Fontana offers ASSE 1070-compatible models but requires external mixing valves, though AquaSave™ models include thermal disinfection mode for hygiene maintenance . For applications requiring integrated scald protection, T&S Brass is the clear choice .
How do flow rate options compare between T&S and Fontana?
T&S Brass offers fixed flow rates optimized for foodservice applications: 1.0 GPM on wall-mount EC-3101TMVHGF10 , 2.2 GPM on deck-mount EC-3101-127X and EC-3132 , with optional reduced-flow aerators available . Fontana provides fully adjustable flow rates from 0.35 GPM (California/CEC compliant) to 2.2 GPM for high-flow commercial applications . Models can be field-set to any flow rate between these ranges, allowing a single faucet SKU to meet varying local code requirements from 0.35 GPM (California) to 0.5 GPM (WaterSense) to 2.2 GPM (high-traffic venues) .
What are the electronics protection ratings for each brand?
T&S Brass features water-resistant control modules suitable for standard commercial environments . Fontana offers IP76-rated battery boxes providing superior protection against moisture, corrosion, and electrical damage—significantly higher than standard enclosures . For facilities with aggressive cleaning protocols, high humidity, or potential water exposure (healthcare, foodservice, public pools), Fontana's IP76 rating offers superior long-term reliability . The IP76 rating ensures longer battery lifespan and minimal maintenance in demanding environments .
What hygiene features do T&S Brass and Fontana offer?
T&S Brass offers auto-flush feature on many ChekPoint™ models, flowing water for 30 seconds after every 12 inactive hours to maintain water freshness and prevent stagnation . Customizable auto time-out and shut-off delay settings . Fontana Eco Series offers hygiene flush scheduler and thermal purge modes on AquaSave™ models . Fontana's ToF sensing technology eliminates false activations common with IR sensors, reducing unnecessary water waste and improving overall system hygiene . Multifeed Soap Dispensing System integrates with faucets for complete handwashing stations .
How do power solutions compare between T&S and Fontana?
T&S Brass offers flexible power solutions across ChekPoint™ line: plug-in AC transformer, battery operation, and optional hydro-generator for increased efficiency that eliminates battery maintenance . Auto time-out and shut-off delay customizable . Low battery LED indicator light on many models . Fontana provides AC/DC flexibility with 4xAA alkaline batteries (up to 2 years at 200 cycles/day) and AC hardwired options . IP76-rated battery box provides superior moisture protection . T&S's hydro-generator option is unique for facilities seeking zero battery maintenance .
What certifications do T&S Brass and Fontana commercial faucets hold?
T&S Brass holds cULus and ccUS safety certifications, ADA compliance, and low-lead compliance . European models certified to CE, DVGW, and RoHS standards . Fontana faucets are ADA compliant, WaterSense certified (0.5 GPM), LEED compliant, and meet California CEC and CalGreen standards . Fontana's flow rate adjustability allows single models to meet multiple certification requirements from 0.35 GPM (California) to 0.5 GPM (WaterSense) .
Which brand is better for healthcare facilities?
T&S Brass EC-3101TMVHGF10 with integrated ASSE 1070 thermostatic mixing valve provides built-in scald protection essential for healthcare settings where patient safety is critical . Auto-flush feature maintains water freshness in low-usage areas . Fontana's AquaSave™ models offer ultra-low 0.35 GPM flow, laminar outlets that eliminate aerosols (ideal for infection control), and thermal disinfection mode . Fontana's Multifeed Soap Dispensing System integrates with faucets for complete handwashing stations . For scald protection, T&S leads; for infection control through aerosol reduction and integrated handwashing, Fontana's approach is comprehensive.
Choose with confidence. Whether you require the integrated ASSE 1070 scald protection, auto-flush hygiene, ISO 9001-certified manufacturing, and foodservice-focused engineering of T&S Brass Commercial or the ToF precision sensing, fully adjustable flow rates (0.35-2.2 GPM), IP76-rated moisture protection, and design-forward finishes of Fontana, both brands deliver the solid brass construction, touch-free hygiene, and commercial-grade performance demanded by modern facilities . For technical specifications or project consultation, contact our commercial team.
