Fontana Sierra Matte Black Automatic Sensor Faucet

Fontana Denver Commercial Chrome Touchless Automatic Sensor Hands Free Faucet

Alternative Views:

Retail Price: $892.47

starting at: $735.11

Price with Selected Options: $735.11

Commercial Orders: Need RFQ Click Here

Availability: Usually Ships in 5 to 10 Business Days
Product Code: FS-509B

Hot & Cold Option:

Qty:

Description

Technical Specs

Extended Technical Information

Fontana Sierra Commercial Matte Black Automatic Sensor Faucet

Denver Commercial Chrome Sensor Sink Faucet delivers precision touchless functionality for commercial washrooms where sanitation compliance, water efficiency, and operational consistency are essential. The intelligent infrared activation system ameliorates bacterial transfer, excessive fixture contact, uncontrolled discharge cycles, and maintenance-heavy manual operation. Inferior chrome sensor faucets often experience calibration drift, pressure instability, delayed shutoff performance, actuator fatigue, and mineral scaling accumulation that increase service requirements and ownership costs. Commercial-grade hydraulic engineering ensures reliable low-flow operation and consistent activation responsiveness. Suitable for hospitals, airports, educational campuses, transportation infrastructure, hospitality developments, and institutional restroom projects requiring dependable touchless water delivery.

Motion detection touchless sensor faucet operation

Sensitive Sensor with Infrared AI Smart-Chip

Factory set to 30-second Auto Shutoff (can be adjusted).

Water Pressure: 0.5 - 7.0 KGS/cm, 10 - 125 psi

Solid Brass Construction, Matte Black Finish

Easy to Install - Instructions Included

Water-resistant solenoid enclosure

Advanced energy-saving design for long-lasting battery life

Comes complete with Hoses & Accessories

Power Supply: AC110V And DC6V (batteries not included)

AC/DC power option.

ADA Compliant.

Can be installed easily in new or upgraded retrofit commercial bathrooms.

Usage: Commercial

Ideal for commercial use applications in public restrooms, restaurants, office buildings, public facilities, and hospitals. Fits all standard US plumbing.

Reduces the transfer of germs by preventing cross-contamination and re-contamination of germs and bacteria by not touching the faucets or handles. Cut down on water usage by minimizing waste of water by eliminating unnecessary or unattended water flow.

Sensor Activated Faucet Special Features

Durable Vandal-Resistant Brass Body; Ideal for commercial high use applications
Intelligent: with its micro-computer controlling its action, the faucet will self-adjust its best detection zone as per the color and shape of the lavatory
Flashing light indicator; a diagnostic indicator for power up, low battery, and solenoid function.
The meaning of the codes is described in the installation instructions.
Convenient to maintain; with a built-in strainer to prevent sundries from entering the solenoid valve and the strainer is easy to clean
The faucet can be mounted to any sink surface.
ADA Compliant.
The battery's life is 8,000 cycles per month and with enough water pressure is approx 5 years service life of the batteries.
Adjustable sensing range; while the factory range is set about 4" to 5" from the sensor, it can be adjusted.

Specifications

Diameter of inlet pipe: DN15
Diameter of outlet pipe: DN15
Water Pressure: 0.05Mpa - 0.7Mpa
Power: DC.6V
Power Consumption: 0.5MW
Detection Zone: Factory set 25cm/10" (based on standard inductive board)
Ambient Temperature: 1 - 45 Â°C / 33.8 -113 Â°F
Degree of protection by enclosure: 1P56
Battery: 4 x 'AA' size cells
Operational water pressure range: 0.05 - 0.6MPa
US standard water supply pipe size: DN15 (G1/2")
Ambient temperature range: 0.1 - 45ÂºC
Sensing distance: 9.84" (25cm)
Time delay: 0.5 seconds
Operation duration: Power will automatically cut off after continuous use for 60 seconds
Manufacturer Warranty: 10-Years
Color: Chrome
